Novawinch

33,000lb/14,965kg Military Rated Hydraulic Recovery Winch

SKU:
{sku}
$6,793.45ex.VAT
was
£0.00
Save 0
:
Thank you! Your submission has been received!
Buy now, pay later options available at checkout
Visa Logo
Mastercard Logo
Google Pay Logo
Paypal Logo
Klarna Logo

What's in the box?

Description

Military-Grade Durability & Industrial Power

Introducing the NOVAWINCH HW150 33,000lb (14,956kg) Military Rated Hydraulic Winch. Engineered to surpass standard commercial demands, the HW Series tackles the toughest industrial jobs on the planet. Whether outfitting a military tactical vehicle or a heavy commercial recovery truck, this winch provides the rugged reliability needed when failure is not an option.

Certified Safety and Efficiency

The HW150 isn't just strong; it's also safe. It is fully compliant with EN14492-1:2006 requirements, guaranteeing it meets the rigorous safety and efficiency standards for professional UK and European operators. This makes it an ideal solution for fleet managers who prioritise compliance alongside raw power.

Key Features & Benefits:

  • 33,000lb (14,956kg) Capacity: Massive hydraulic pulling power for recovering heavy plant and commercial vehicles.
  • Military Rated Engineering: Built to withstand shock, vibration, and extreme environments far beyond standard commercial winches.
  • EN14492-1 Compliant: Certified to meet strict European safety standards for power-driven winches.
  • HW Series Robustness: Engineered for consistent high-performance in mining, construction, and defence sectors.
  • Versatile Application: The trusted choice for recovery trucks, flat-bed trailers, tractors, and fire service vehicles.

Specifications

Performance by Layer

Layer Rated Line Pull Line Speed Wire Rope Capacity
1 33,000 lb (14,965 kg) 13.1 fpm (4.0 m/min) 36.0 ft (11.0 m)
2 29,117 lb (13,205 kg) 14.8 fpm (4.5 m/min) 85.0 ft (26.0 m)
3 26,052 lb (11,815 kg) 16.5 fpm (5.0 m/min) 137.0 ft (42.0 m)
4 23,571 lb (10,690 kg) 18.3 fpm (5.6 m/min) 196.0 ft (60.0 m)

Technical Specifications

First Layer Line Pull 33,000 lb (14,965 kg / 14.9 Tonne)
First Layer Line Speed Normal: 13.1 fpm (4.0 m/min) / High: 49.0 fpm (15 m/min)
Working Pressure Diff. 2,320 psi (16 MPa)
Oil Flow Supply 70 l/min
Gear Ratio 84:1
Wire Rope Diameter 3/4" (20 mm)
Rope Layers 4
Wire Rope Capacity 196.0 ft (60 m)
Valve Model NF-120 P1 S1-003
Net Weight (Excl. Rope) 882.0 lb (400 kg)
